Model Number

1

DDW1802W
2

Diagram of the component your part is located in:

Section 1 Image 1

Click to View Diagram

Description	Part#	Substitution#	Diagram Reff	ETA
KNOB BLUE PLASTIC SHAFT	1802.90-1			3 days
KNOB PANEL - FOR KNOB WITH BLUE PLASTIC SHAFT	1802.91-1			11 days
FLOAT HOSE	1806.139			3 days
EXTERNAL HOSE	1802.1		1	3 days
FLOAT SWITCH	1802.10		10	3 days
DOOR FOAM	1802.101		101	11 days
DOOR EDGE GUARD	1802.102		102	3 days
DETERGENT DISPENSER	1802.103		103	3 days
LEFT UPRIGHTS ASSY	1802.108		108	11 days
LOWER REAR CROSSPIECE	1802.109		109	3 days
FLOAT	1802.11		11	3 days
DOOR LOCK HOOK AND COUPLING BLOCK	1802.113	673001300170	113	3 days
UPPER FRONT CROSSPIECE	1802.115		115	11 days
RIGHT UPRIGHTS ASSY	1802.117		117	11 days
UPPER BASKET CUP SUPPORT	1802.111		119	3 days
FILTER ASSY	1802.12		12	3 days
UPPER BASKET ASSY	1802.119	12976000001405	120	11 days
LOWER BASKET ASSY	1802.121	12976000001398	121	11 days
CUTLERY BASKET	1802.125		125	3 days
GUIDE RAIL BLOCK	1802.129		129	3 days
MICROFILTER	1802.13		13	3 days
GUIDE RAIL	1802.130		130	3 days
GUIDE RAIL BRACKET ASSY	1802.131	12176000010344	131	11 days
JUNCTION BOX	1802.167		132	11 days
BASEBOARD	1802.133		133	3 days
FOOT REST ASSY	1802.135		135	11 days
LOWER FRONT CROSSPIECE	1802.137		137	3 days
CUP DAMPING RING NUT	1802.14		14	3 days
LEVELING LEG	1802.140		140	11 days
TUB ASSY	1802.144		144	11 days
ASSEMBLING HOOK	1802.146		146	11 days
SOUND INSULATION FIBER	1802.147		147	3 days
CONNECTING DUCT FOR EXTERNAL HOSE	1802.15	12676000000714	15	11 days
THERMOSTAT (78°C)	1802.41		16	3 days
CUP GASKET	1802.17		17	3 days
CUP ASSY	1802.18		18	3 days
O RING	1802.2		2	3 days
DRAIN PUMP	1802.23	11001011000207	23	11 days
SALT CHANNEL	1802.28		28	3 days
SOFTENER CAP ASSY	1802.29		29	3 days
GUIDE CASING	1802.3		3	3 days
GUIDE CASING	1802.3		30	3 days
SOFTENER GASKET	1802.31		31	3 days
ADJUSTABLE SOFTENER	1802.32		33	3 days
DRAIN HOSE	1802.35		35	3 days
INLET VALVE	1802.39	17476000001132	39	11 days
NUT	1802.4		4	3 days
THERMOSTAT ASSY (58°C 45°C)	1802.16		41	3 days
COUPLING CASING FOR PROTECTION THERMOSTAT	1802.42		42	3 days
O RING FOR GUIDE RAIL BRACKET	1802.43		43	3 days
RING NUT	1802.44		44	3 days
HEATING ELEMNETS	1802.45		45	3 days
CONNECTING DUCT	1802.46		46	3 days
PRESSURE SWITCH	1802.47		47	3 days
PVC HOSE FOR PRESSURE SWITCH	1802.48		48	3 days
FEEDING DISPENSER ASSY	1802.5	12176000009057	5	11 days
MOTOR PUMP ASSY	1802.53		53	3 days
LOWER MANIFOLD SUPPORT	1802.54		54	3 days
LOWER SPRAYER SHIFT	1802.55		55	3 days
CONNECTING RING NUT	1802.56		56	3 days
LOWER SPRAY ARM	1802.57		57	3 days
UPPER SPRAY ARM	1802.58	12176000009073	58	11 days
REGENERATION HOSE	1802.59		59	3 days
DRAIN HOSE OF AIR BREAKER	1802.6		6	3 days
DRAIN HOSE OF AIR BREAKER	1802.6		60	3 days
INLET HOSE OF AIR BREAKER	1802.61		61	3 days
O RING	1802.2		62	3 days
RING NUT OF AIR BREAKER	1802.64		64	3 days
AIR INLET	1802.65		65	3 days
AIR BREAKER ASSY	1802.66		66	3 days
O RING	1802.2		67	3 days
RING NUT OF AIR BREAKER	1802.64		68	3 days
RING NUT FOR FASTENING LOWER MANIFOLD	1802.7		70	11 days
PIPE FOR TOP SPRAYING NOZZLE	1802.72		72	3 days
CONNECTOR FOR TOP SPRAYER NOZZLE	1802.73		73	3 days
O RING	1802.2		74	3 days
TOP SPRAYING NOZZLE	1802.76		76	3 days
INNER DOOR & GASKET	1802.77		77	3 days
INDICATOR LAMP	1802.78		78	3 days
BUTTON	1802.79		79	3 days
FLOAT SWITCH SUPPORT	1802.8		8	3 days
POWER SWITCH	1802.80		80	3 days
NON POLAR SWITCH	1802.81		81	3 days
BI-POLAR CONTROL SWITCH	1802.82		82	3 days
HANDLE ASSY	1802.85		85	3 days
TIMER	1802.86		86	3 days
CONTROL PANEL	1802.88		88	3 days
KNOB - BRASS SHAFT	1802.9		90	3 days
KNOB PANEL - FOR KNOB WITH BRASS SHAFT	1802.91		91	3 days
OUTER DOOR	1802.92		92	3 days
DOOR SPRING	1802.96		96	3 days
HINGE ASSY	1802.97		97	11 days
RIGHT HINGE ASSY	1802.98		98	11 days
LEFT HINGE ASSY	1802.99		99	11 days
SPRAY ARM GASKET	2903013104		ns	3 days
TUB GASKET	2903015206	12676000000779	ns	11 days
